Style KXT 600-CG Spiral wound gasket with outer ring
Spiral wound gasket with outer ring with suitable dimensioning of the centering ring, the sealing element is accurately centered on
the flange face by the bolts. A general purpose gasket for use with flat face and raised face flanges
Advantages
•Automatically adjusts to the changes of the pressure, temperature and vibration
•Used for high pressure and high temperature
•Can often be used where other gasket failed
•Wide choice for metal strip and fillers
• Easy installation
Good Sealing Effect
•Excellent sealing capability on the irregular flange surface
•Excellent sealing capability compared to the size
•Nearly zero leakage
Cheap Price
•Any shape of size is available with reasonable price
•Good production capacity & short delivery time
Application
•High temperature & pressure equipment
•Extreme Low temperature equipment
•General flangegasket
•Raised face flange
•Flat face flange
•Pump
•Valve., etc
SPIRAL WOUND GASEKT
Style KXT 600 CGI Spiral Wound Gasket with Inner and Outer Ring
The standard version is the Style CGI spiral wound gasket with inner and outer ring. This gasket has
the best sealing characteristicscombined with the highest safety for flanged joints with flat face and
raised face
Advantages
•Automatically adjusts to the changes of the pressure, temperature and vibration
• Highest safety for flanged joints with flat face and raised face flanges
•This style gasket has the best sealing characteristics
Good Sealing Effect
•Excellent sealing capability on the irregular flange surface
•Prevents turbulence and erosion damage to flange
•Acts as corrosion barrier protecting
•Acts as heat shield
Application
•High temperature & pressure equipment
•Flat flange and raised flange
•Pump
•Valve., etc
Package:
Spiral wound gasket: packaged with plastic film, and in wooden pallets or cases.
Shipping:
Spiral wound gasket: by sea, by train or by air.
